Large Format Aerial Camera System
Based on the design of IGI’s DigiCAM with integrated Phase One camera modules the IGI Large Format DigiCAM features the same high geometric accuracy, broad dynamic range and full metric capabilities at a larger format.
With the IGIvisu operator interface and IGI IPS software image capture and quality control is easily done during and after the flight.
Being part of IGI’s Modular System Concept, the camera can be upgraded to a 2-IN-1 large format and
oblique aerial camera system.
DigiCAM-450
- Image size 30,460 x 14,100 px
- Sensor Technology: Phase One BSI-CMOS
- Pixel Size : 3,76
- High Dynamic Range 83dB
- Channels: RGBI, RGB, CIR, NIR
- Convertible from Large Format to Oblique Camera System (IGI Dual Housing)
- IGI SMU-2 (Sensor Management Unit)
- Up to 8TB Storage Units (with RAID Option)
- Integrated Mission Planning & Flight Guidance (CCNS-5 & IGIplan)
- Integrated Sensor Management (IGIvisu)
- Integrated GNSS/IMU System (AEROcontrol)
- 10" or 20" Operator Screen
Dual DigiCAM-300
- Image size 22,000 x 13,400 px
- Sensor Technology: Phase One BSI-CMOS
- Pixel Size : 3,76
- High Dynamic Range 83dB
- Channels: RGBI, RGB, CIR, NIR
- Convertible from Large Format to Oblique Camera System (IGI Dual Housing)
- IGI SMU-2 (Sensor Management Unit)
- Up to 6TB Storage Units (with RAID Option)
- Integrated Mission Planning & Flight Guidance (CCNS-5 & IGIplan)
- Integrated Sensor Management (IGIvisu)
- Integrated GNSS/IMU System (AEROcontrol)
- 10" or 20" Operator Screen
Dual DigiCAM-200
- Image size 17,500 x 11,400 px
- Sensor Technology: Phase One BSI-CMOS
- Pixel Size : 3,76
- High Dynamic Range 83dB
- Channels: RGBI, RGB, CIR, NIR
- Convertible from Large Format to Oblique Camera System (IGI Dual Housing)
- IGI SMU-2 (Sensor Management Unit)
- Up to 6TB Storage Units (with RAID Option)
- Integrated Mission Planning & Flight Guidance (CCNS-5 & IGIplan)
- Integrated Sensor Management (IGIvisu)
- Integrated GNSS/IMU System (AEROcontrol)
- 10" or 20" Operator Screen
